A 3-point, PTO-driven flail mower built for verges, ditch banks and road shoulders. A hydraulic arm swings the 71-inch cutting head out to the side -- and tilts it -- so the tractor runs along flat ground while the head does the work on the bank or slope beside it.
Includes free nationwide freight shipping (curbside delivery).
New and unused, held in US stock.
Added to your basket. View basket
Buy now takes you straight to checkout with this machine in your basket.
Built for the job
The cutting head swings out to the side on a hydraulic arm, so you mow the verge, ditch bank or shoulder while the tractor itself stays on flat, stable ground instead of leaning down the slope.
The head angles on the arm as well as swinging out, so the cut follows the bank's slope rather than sitting flat against it.
A hammer-blade (flail) rotor mulches rough growth, brambles and small saplings without throwing debris the way a rotary blade does.
Mounts on a standard rear 3-point hitch and runs off the tractor's PTO -- no separate engine to fuel or service.
Sized for the kind of tractor that already does road-shoulder, ditch and right-of-way work.
The model number is stamped on the machine itself, so parts and service enquiries are easy to identify.
Full specification
| Model | GroundMaxx VHF71 |
|---|---|
| Cutting width | 71 in |
| Cutting system | PTO-driven flail (hammer-blade) rotor |
| Mounting | 3-point, rear-mounted |
| Offset arm | Hydraulic side-offset, with head tilt |
| Recommended tractor | 60-100 HP |
| Hitch category | Category-appropriate 3-point hitch -- confirm Cat. I/II with us before ordering |
| Driveline | PTO shaft included |
Specifications are nominal and may vary slightly by production batch.
Questions
The cutting head is mounted on a hydraulic arm that swings out to the side of the tractor, and tilts, so you can mow a ditch bank, verge or road shoulder while the tractor itself stays on flat ground. It is not a straight rear-mounted mower.
The VHF71 is built for tractors in the 60-100 HP range. Check your tractor's rear hydraulic remotes (the offset arm and head tilt are hydraulically actuated) and 3-point hitch category against the machine before you order, and ask us if you are not sure.
We are confirming the exact offset reach, blade count and gearbox ratio with the manufacturer and will publish them here rather than estimate them. Email us if you need a figure before you order and we will confirm it in writing.
We are confirming the rated PTO speed (540 or 1000 rpm) with the manufacturer before publishing it. Please ask us to confirm before ordering if this affects your tractor's PTO output.
The VHF71 uses a category-appropriate 3-point hitch. Confirm Category I or Category II with us against your tractor before you order.
Yes -- the PTO driveline shaft ships with the machine, as shown in the photographs.
